Emtron DX-1SP/>
| Type: |
Power Amplifier |
| Frequency Range: |
10-160 m + WARC |
| Voltage: |
Mains: 100-240 VAC |
| Current Drain: |
10 A @ 240 VAC |
| Drive power: |
30-60 W |
| Maximum output power: |
SSB: 1.5 KW (PEP)
CW: 1.2 KW |
| Dimensions (W*H*D): |
380 x 190 x 355 mm (15 x 7.5 x 14 inches) |
| Weight: |
20 Kg (44 lb) |
| Manufactured: |
Australia: 20xx-201x |
| Other: |
Modular design with interchangeability between models.
Power device: 1*FU-728F tube.
Optional full QSK module. |
| Related Documents: |
|
 |
